CargoSecure Dunnage Bag 120 x 180 cm
For low pallets with a gap of up to 55 cm
Article number: 09-01-0301-01
| Article number | 09-01-0304-01 | 09-01-0303-01 | 09-01-0302-01 | 09-01-0301-01 |
|---|---|---|---|---|
| Application | Containers, Train wagons, Trucks | Containers, Train wagons, Trucks | Containers, Train wagons, Trucks | Containers, Train wagons, Trucks |
| Colour | White | White | White | White |
| Industry | Transport & Logistics | Transport & Logistics | Transport & Logistics | Transport & Logistics |
| Length | 120 cm | 180 cm | 180 cm | 210 cm |
| Material | Polyethylene, Polypropylene | Polyethylene, Polypropylene | Polyethylene, Polypropylene | Polyethylene, Polypropylene |
| Size | 90 x 120 cm | 90 x 180 cm | 120 x 180 cm | 120 x 210 cm |
| Thickness | 72 micron | 72 micron | 72 micron | 72 micron |
| Weight | 360 g | 520 g | 695 g | 790 g |
| Width | 90 cm | 90 cm | 120 cm | 120 cm |
The CargoPlus Dunnage Bag Level 1 is a reusable dunnage bag with AAR Level 1 approval, in four sizes. The bag has an 85 g/m² outer layer and a 72 micron inner layer, and withstands pressure up to 0.55 bar. The CargoPlus is supplied per full pallet and ships within 5 working days.
For gaps up to 35 cm, there is the 90 x 120 cm for low pallets, with 650 pieces per pallet, and the 90 x 180 cm for tall or stacked pallets, with 500 pieces per pallet. For gaps up to 55 cm, there is the 120 x 180 cm, with 400 pieces per pallet, and the 120 x 210 cm for tall pallets, with 360 pieces per pallet.
The woven polypropylene outer layer weighs 85 g/m², the airtight polyethylene inner layer is 72 micron thick. This allows the bag to withstand a maximum pressure of 0.55 bar, higher than the 0.46 bar of the CargoSecure.
The CargoPlus is supplied per full pallet only and ships within 5 working days. Quotes for multiple pallets are available on request.
The valve allows inflating and deflating, so the bag can be used 2 to 3 times. The bag should hang at least 10 cm above the floor and be checked for damage before reuse. The Cargo Air Gun and the Portable Air Master are both suitable for inflation.
A full pallet of CargoPlus dunnage bags with AAR Level 1 holds 650 pieces of 90 x 120 cm, 500 pieces of 90 x 180 cm, 400 pieces of 120 x 180 cm or 360 pieces of 120 x 210 cm. The CargoPlus is supplied per full pallet only and ships within 5 working days.
A CargoPlus dunnage bag has a heavier 85 g/m² outer layer and a thicker 72 micron inner layer. This allows the bag to withstand up to 0.55 bar, compared with 0.46 bar for the CargoSecure. That extra margin matters in rail transport and with heavy loads, where greater forces act on the bag.
